Arktek Deep Freeze Dry Ice Vaccine Storage Device

p

See price above for discounted price

The pricing we offer to our customers is manufacturer direct pricing, and is only available to our VIA Verified Buyer network. Please request a quote for more information, or sign up as a Verified Buyer to be able to log in and view pricing and place orders.

The Arktek DF – Dry Ice is a super-insulated container that safely stores vaccines between -60℃ to -80℃ for 6.5 days and longer under hot zone conditions of 43℃. This device does not require any external power – only dry ice.
• Minimum Order Quantity (MOQ): 1 piece
• Seller Name: AUCMA Global Medical
• Seller Location: China
• Warranty Term: 3 years
• Regulatory Approval: ISO 9001
• Product Variations: Arktek Deep Freeze PCM Vaccine Storage Device

Additional information

Weight 32.5 kg
Dimensions 65 × 65 × 89 cm

Description

The Arktek DF - Dry Ice is a super-insulated container that safely stores vaccines between -60℃ to -80℃ for 6.5 days and longer under hot zone conditions of 43℃. This device does not require any external power - only dry ice (not included).

Health workers can easily retrieve and replace the vaccine vial stacks several times per day as the Arktek continues to stay cold and protect the vaccines. Vaccines and ice blocks are loaded into the Arktek DF through the opening at the top of the device. The ice blocks are first stacked against the inner wall and the vaccine carrier cups are then placed in the center.

Key Features

Usability
The Arktek DF – Dry Ice can hold vaccines between -60℃ to -80℃ for almost 7 days at hot zone temperature environment of 43℃/5℃.
Longer hold times are possible when storage temperature requirements are above -40℃.

Design
The Arktek can be used in cold chain distribution of vaccines.

Safety
The Arktek DF – Dry Ice is equipped with a HOBO 4-channel thermocouple logger (HOBO) which is attached to four thermocouple (TC) sensors which monitor interior temperatures in the vaccine storage area of the Arktek. The AAA battery required to power the LCD screen does not ship with the device.

Specifications

Measurements

  • External Dimensions (OD*H): 52.8 x 74.7 cm
  • Capacity: 5.4 L
  • Net Weight: 32.5 kg
  • Gross Weight: 37 kg

Operating Environment

  • Vaccine Storage Temperature: -60℃ to -80℃
  • Hold time: 7 days at 43℃/5℃ ambient temperature with daily use

Standard Accessories

  • Vaccine containers (13x small/short)
  • Ice blocks (two full sets) (16x)

Optional Accessories & Add-ons

Not applicable

Product Documents, Manuals & Brochures

User Manual

Brochure

Regulatory Certificates

ISO 9001 Certificate

Videos

Not available at this time



FAQ

How many vaccines can be held within the Arktek DF?
There are 3 vaccine stacks in the device. One middle stack (consisting of five small cups) and two side stacks (each consisting of four small cups).
Each small cup can load 4 ampules (2ml), 14 common vials (4ml) and 4 wide vials (8ml).

Studies & Trials

Not available at this time



Package Contents

  • 1x Arktek DF – Dry Ice
  • 13x Vaccine containers (small/short)
  • 16x Ice blocks (two full sets)

Warranty

Three-year warranty on the device is included at no extra cost. Under warranty coverage, the manufacturer will repair or replace device components that have failed in the use of the device for its designed intent.

Free warranty coverage does not include the following cases:
Damage caused by improper use or improper maintenance.
Damage caused by attempted repairs done by a non-designated repair department.
Damage caused by force majeure.
Damage occurring after the warranty period has expired.

Testimonials

Not available at this time
