MTTS Lightmeter
Category: Hospital & Clinic
SKU: SKU: LM-800
From $350.00 USD
The MTTS Lightmeter provides precise measurement of the intensity of the blue light spectrum that is necessary to treat jaundice in infants. This measurement allows health professionals to ensure phototherapy units are working correctly and determine when a phototherapy device or its bulbs need to be replaced. The Lightmeter was developed for use with the MTTS Firefly and MTTS Colibri Overhead Phototherapy, but it can be used for any phototherapy unit with LEDs, fluorescent bulbs or compact bulbs. When measuring a single-sided phototherapy machine, the Lightmeter will measure the light using t…
Specifications
- Battery: • Type: 2 x AAA 1.5V Alkaline, non-rechargeable batteries (not included) • Lifetime: Up to 120h operating time
- Service: • Calibration: Required • Calibration Schedule: Every 2 years, measured from delivery date; Return to Seller for calibration
- Performance: • Application: LED and blue fluorescent phototherapy light sources; using the lightmeter for halogen phototherapy results in a minor but not considerable error • Measurement Range: Single sided: 0.1 to 150 µW/cm^2/nm Double sided: 0.1 to 300 µW/cm^2/nm Spectral Response: 400 nm to 500 nm Accuracy: +/- 3% • Single sided: 0.1 to 150 µW/cm^2/nm • Double sided: 0.1 to 300 µW/cm^2/nm • Spectral Response: 400 nm to 500 nm • Accuracy: +/- 3%
- Display Type: • Touch screen liquid-crystal display (LCD)
- Operating Environment: • Temperature: 10°C to 40°C • Humidity: 30 to 90% RH • Atmospheric Pressure: 70 – 160 kPA
- Transport and Storage: • Temperature: 0°C to 50°C • Humidity: 5 to 90% RH • Atmospheric Pressure: 70 – 160 kPA
Documents & Certificates
Available in these markets
VIA Global Health ships MTTS Lightmeter to healthcare providers, distributors, and NGOs across the following countries:
